Specifications
- Vceon Max Vge Ic
- 2.45V @ 15V, 150A
- Turn Off Timenom Toff
- 1300 ns
- Terminal Pozisyonu
- UPPER
- Terminal Sayısı
- 29
- Current Collector Cutoff Max
- 3mA
- Yayın Yılı
- 2002
- ECCN Kodu
- EAR99
- Transistor Element Material
- SILICON
- Yüzey Montaj
- NO
- Montaj Tipi
- Chassis Mount
- Kurşunsuz Kodu
- no
- Voltage Collector Emitter Breakdown Max
- 1700V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Input Capacitance Cies Vce
- 13.5nF @ 25V
- Igbt Type
- Trench Field Stop
- Qualification Status
- Not Qualified
- Ntc Thermistor
- Yes
- Polaritychannel Type
- N-CHANNEL
- Çalışma Sıcaklığı
- -40°C~125°C
- Turn On Time
- 366 ns
- Case Connection
- ISOLATED
- Currentcollector Ic Max
- 240A
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Number Of Elements
- 6
- Seri
- EconoPACK™+
- Terminal Formu
- UNSPECIFIED
- Parça Durumu
- Not For New Designs
- Pin Sayısı
- 29
- Kılıf / Paket
- Module
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Configuration
- Full Bridge
- Power Max
- 1050W
- RoHS Durumu
- ROHS3 Compliant
- Input
- Standard
- Jesd30 Code
- R-XUFM-X29
