Volume pricing
- 1+ pcs$111.36
- 10+ pcs$105.06
- 100+ pcs$99.11
- 500+ pcs$93.50
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Kurşunsuz Kodu
- no
- Montaj Tipi
- Chassis Mount
- Voltage Collector Emitter Breakdown Max
- 1200V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Input Capacitance Cies Vce
- 9.35nF @ 25V
- Transistor Application
- POWER CONTROL
- Terminal Sayısı
- 20
- Terminal Pozisyonu
- UPPER
- Turn Off Timenom Toff
- 600 ns
- Vceon Max Vge Ic
- 2.15V @ 15V, 150A
- Yayın Yılı
- 2003
- ECCN Kodu
- EAR99
- Transistor Element Material
- SILICON
- Current Collector Cutoff Max
- 1mA
- Yüzey Montaj
- NO
- Polaritychannel Type
- N-CHANNEL
- Igbt Type
- Trench Field Stop
- Ntc Thermistor
- Yes
- Qualification Status
- Not Qualified
- Terminal Formu
- UNSPECIFIED
- Turn On Time
- 190 ns
- Çalışma Sıcaklığı
- -40°C~150°C
- Currentcollector Ic Max
- 200A
- Case Connection
- ISOLATED
- Fabrika Tedarik Süresi
- 26 Weeks
- Number Of Elements
- 6
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Power Max
- 680W
- RoHS Durumu
- RoHS Compliant
- Input
- Standard
- Jesd30 Code
- R-XUFM-X20
- REACH Uyumluluk Kodu
- compliant
- Kılıf / Paket
- Module
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Parça Durumu
- Active
- Pin Sayısı
- 20
- Configuration
- Three Phase Inverter
