Volume pricing
- 1+ pcs$137.92
- 10+ pcs$130.11
- 100+ pcs$122.75
- 500+ pcs$115.80
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj Tipi
- Chassis Mount
- Kurşunsuz Kodu
- no
- Input Capacitance Cies Vce
- 10.5nF @ 25V
- Nem Hassasiyeti (MSL)
- Not Applicable
- Voltage Collector Emitter Breakdown Max
- 1200V
- Terminal Sayısı
- 35
- Terminal Pozisyonu
- UPPER
- Vceon Max Vge Ic
- 2.15V @ 15V, 150A
- Turn Off Timenom Toff
- 610 ns
- Yüzey Montaj
- NO
- Transistor Element Material
- SILICON
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2002
- Current Collector Cutoff Max
- 5mA
- Polaritychannel Type
- N-CHANNEL
- Halogen Free
- Not Halogen Free
- Igbt Type
- Trench Field Stop
- Ntc Thermistor
- Yes
- Qualification Status
- Not Qualified
- Kurşunsuz
- Contains Lead
- Terminal Formu
- UNSPECIFIED
- Turn On Time
- 340 ns
- Çalışma Sıcaklığı
- -40°C~125°C
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Number Of Elements
- 6
- Case Connection
- ISOLATED
- Currentcollector Ic Max
- 200A
- Fabrika Tedarik Süresi
- 16 Weeks
- RoHS Durumu
- RoHS Compliant
- Input
- Standard
- Jesd30 Code
- R-XUFM-X35
- Power Max
- 700W
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Kılıf / Paket
- Module
- Pin Sayısı
- 35
- Parça Durumu
- Active
- Configuration
- Three Phase Inverter
