Volume pricing
- 1+ pcs$265.58
- 10+ pcs$250.55
- 100+ pcs$236.37
- 500+ pcs$222.99
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Polaritychannel Type
- N-CHANNEL
- Halogen Free
- Not Halogen Free
- Ntc Thermistor
- Yes
- Montaj
- Screw
- Qualification Status
- Not Qualified
- Kurşunsuz
- Contains Lead
- Igbt Type
- Trench Field Stop
- Input Capacitance Cies Vce
- 10.5nF @ 25V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Collectoremitter Saturation Voltage
- 1.7V
- Voltage Collector Emitter Breakdown Max
- 1200V
- Collector Emitter Voltage Vceo
- 1.2kV
- Montaj Tipi
- Chassis Mount
- Kurşunsuz Kodu
- no
- Max Collector Current
- 200A
- Collectoremitter Breakdown Voltage
- 1.2kV
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2002
- Transistor Element Material
- SILICON
- Current Collector Cutoff Max
- 5mA
- Terminal Pozisyonu
- UPPER
- Terminal Sayısı
- 29
- Turn Off Timenom Toff
- 810 ns
- Vceon Max Vge Ic
- 2.15V @ 15V, 150A
- RoHS Durumu
- ROHS3 Compliant
- Input
- Standard
- Jesd30 Code
- R-XUFM-X29
- Power Max
- 695W
- Configuration
- Three Phase Inverter
- Kılıf / Paket
- Module
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Parça Durumu
- Not For New Designs
- Pin Sayısı
- 29
- Terminal Formu
- UNSPECIFIED
- Pin Sayısı
- 28
- Seri
- EconoPACK™+
- Number Of Elements
- 6
- Power Dissipation
- 695W
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Case Connection
- ISOLATED
