Specifications
- Ambalaj
- Bulk
- Yükseklik
- 17mm
- Input Capacitance Cies Vce
- 9.3nF @ 25V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Transistor Application
- POWER CONTROL
- Montaj Tipi
- Chassis Mount
- Max Collector Current
- 150A
- Kurşunsuz Kodu
- no
- Collector Emitter Voltage Vceo
- 650V
- Transistor Element Material
- SILICON
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2002
- Current Collector Cutoff Max
- 1mA
- Terminal Sayısı
- 20
- Terminal Pozisyonu
- UPPER
- Vceon Max Vge Ic
- 1.95V @ 15V, 150A
- Turn Off Timenom Toff
- 660 ns
- Halogen Free
- Not Halogen Free
- Polaritychannel Type
- N-CHANNEL
- Ntc Thermistor
- Yes
- Montaj
- PCB
- Kurşunsuz
- Contains Lead
- Igbt Type
- Trench Field Stop
- Terminal Formu
- UNSPECIFIED
- Pin Sayısı
- 4
- Currentcollector Ic Max
- 150A
- Case Connection
- ISOLATED
- Fabrika Tedarik Süresi
- 26 Weeks
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Number Of Elements
- 6
- Max Power Dissipation
- 430W
- Turn On Time
- 150 ns
- Çalışma Sıcaklığı
- -40°C~150°C
- RoHS Durumu
- RoHS Compliant
- Input
- Standard
- Jesd30 Code
- R-XUFM-X20
- Genişlik
- 70.6mm
- Configuration
- Three Phase Inverter
- Kılıf / Paket
- Module
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
