Volume pricing
- 1+ pcs$82.94
- 10+ pcs$78.24
- 100+ pcs$73.81
- 500+ pcs$69.63
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Power Max
- 250W
- RoHS Durumu
- RoHS Compliant
- Jesd30 Code
- R-XUFM-X24
- Input
- Standard
- Configuration
- Three Phase Inverter
- Parça Durumu
- Active
- Pin Sayısı
- 24
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Kılıf / Paket
- Module
- Terminal Formu
- UNSPECIFIED
- Fabrika Tedarik Süresi
- 12 Weeks
- Case Connection
- ISOLATED
- Currentcollector Ic Max
- 95A
- Number Of Elements
- 7
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Çalışma Sıcaklığı
- -40°C~150°C
- Turn On Time
- 170 ns
- Halogen Free
- Not Halogen Free
- Polaritychannel Type
- N-CHANNEL
- Qualification Status
- Not Qualified
- Kurşunsuz
- Contains Lead
- Ntc Thermistor
- Yes
- Igbt Type
- Trench Field Stop
- Voltage Collector Emitter Breakdown Max
- 600V
- Input Capacitance Cies Vce
- 4.6nF @ 25V
- Nem Hassasiyeti (MSL)
- Not Applicable
- Montaj Tipi
- Chassis Mount
- Kurşunsuz Kodu
- no
- Current Collector Cutoff Max
- 1mA
- Transistor Element Material
- SILICON
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2002
- Yüzey Montaj
- NO
- Vceon Max Vge Ic
- 1.9V @ 15V, 75A
- Turn Off Timenom Toff
- 760 ns
- Terminal Sayısı
- 24
- Terminal Pozisyonu
- UPPER
