Volume pricing
- 1+ pcs$83.12
- 10+ pcs$78.42
- 100+ pcs$73.98
- 500+ pcs$69.79
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj Tipi
- Chassis Mount
- Max Collector Current
- 25A
- Nem Hassasiyeti (MSL)
- Not Applicable
- Input Capacitance Cies Vce
- 2.8nF @ 25V
- Transistor Application
- POWER CONTROL
- Voltage Collector Emitter Breakdown Max
- 1200V
- Additional Feature
- UL APPROVED
- Terminal Sayısı
- 35
- Terminal Pozisyonu
- UPPER
- Vceon Max Vge Ic
- 2.15V @ 15V, 50A
- Turn Off Timenom Toff
- 620 ns
- Transistor Element Material
- SILICON
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2013
- Current Collector Cutoff Max
- 1mA
- Polaritychannel Type
- N-CHANNEL
- Igbt Type
- Trench Field Stop
- Ntc Thermistor
- Yes
- Montaj
- Screw
- Pin Sayısı
- 35
- Terminal Formu
- UNSPECIFIED
- Turn On Time
- 210 ns
- Çalışma Sıcaklığı
- -40°C~150°C
- Number Of Elements
- 7
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Case Connection
- ISOLATED
- Currentcollector Ic Max
- 50A
- Fabrika Tedarik Süresi
- 12 Weeks
- Input
- Standard
- RoHS Durumu
- RoHS Compliant
- Power Max
- 280W
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Kılıf / Paket
- Module
- Parça Durumu
- Active
- Configuration
- Three Phase Inverter
