Volume pricing
- 1+ pcs$30.30
- 10+ pcs$28.59
- 100+ pcs$26.97
- 500+ pcs$25.44
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Elements
- 7
- Collector Emitter Voltage Vceo
- 600V
- RoHS Durumu
- RoHS Compliant
- Case Connection
- ISOLATED
- Turn On Time
- 45 ns
- Kılıf / Paket
- Module
- Transistor Application
- POWER CONTROL
- Terminal Sayısı
- 23
- Halogen Free
- Not Halogen Free
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Nem Hassasiyeti (MSL)
- Not Applicable
- Input
- Standard
- Yayın Yılı
- 2002
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -40°C~150°C
- Kurşunsuz
- Contains Lead
- Vceon Max Vge Ic
- 1.9V @ 15V, 50A
- Transistor Element Material
- SILICON
- Ntc Thermistor
- Yes
- ECCN Kodu
- EAR99
- Turn Off Timenom Toff
- 355 ns
- Igbt Type
- Trench Field Stop
- Polaritychannel Type
- N-CHANNEL
- Max Collector Current
- 65A
- Terminal Formu
- UNSPECIFIED
- Current Collector Cutoff Max
- 1mA
- Configuration
- Three Phase Inverter
- Montaj Tipi
- Chassis Mount
- Montaj
- Screw
- Currentcollector Ic Max
- 65A
- Terminal Pozisyonu
- UPPER
- Power Max
- 175W
- Fabrika Tedarik Süresi
- 16 Weeks
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Pin Sayısı
- 23
- Input Capacitance Cies Vce
- 3.1nF @ 25V
