Volume pricing
- 1+ pcs$13.58
- 10+ pcs$12.81
- 100+ pcs$12.09
- 500+ pcs$11.40
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Vceon Max Vge Ic
- 2V @ 15V, 30A
- Ntc Thermistor
- Yes
- Transistor Element Material
- SILICON
- ECCN Kodu
- EAR99
- Turn Off Timenom Toff
- 245 ns
- Radyasyon Dayanımı
- No
- Igbt Type
- Trench Field Stop
- Reach Svhc
- No SVHC
- Polaritychannel Type
- N-CHANNEL
- Max Collector Current
- 37A
- Terminal Formu
- UNSPECIFIED
- Current Collector Cutoff Max
- 1mA
- Configuration
- Three Phase Inverter
- Montaj Tipi
- Chassis Mount
- Kurşunsuz Kodu
- no
- Montaj
- Screw
- Power Max
- 115W
- Terminal Pozisyonu
- UPPER
- Fabrika Tedarik Süresi
- 16 Weeks
- Collectoremitter Breakdown Voltage
- 600V
- Pin Sayısı
- 23
- Max Power Dissipation
- 115W
- Input Capacitance Cies Vce
- 1.65nF @ 25V
- Number Of Elements
- 7
- Collector Emitter Voltage Vceo
- 600V
- RoHS Durumu
- RoHS Compliant
- Case Connection
- ISOLATED
- Kılıf / Paket
- Module
- Turn On Time
- 42 ns
- Transistor Application
- POWER CONTROL
- Terminal Sayısı
- 23
- Nem Hassasiyeti (MSL)
- Not Applicable
- Input
- Standard
- Yayın Yılı
- 2002
- Parça Durumu
- Active
- Pin Sayısı
- 23
- Collectoremitter Saturation Voltage
- 1.55V
- Çalışma Sıcaklığı
- -40°C~150°C
