Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- ECCN Kodu
- EAR99
- Voltage Collector Emitter Breakdown Max
- 1200V
- Vceon Max Vge Ic
- 3.7V @ 15V, 25A
- Ntc Thermistor
- Yes
- Transistor Element Material
- SILICON
- Max Collector Current
- 40A
- Terminal Formu
- UNSPECIFIED
- Turn Off Timenom Toff
- 460 ns
- Polaritychannel Type
- N-CHANNEL
- Fabrika Tedarik Süresi
- 14 Weeks
- Terminal Pozisyonu
- UPPER
- Montaj Tipi
- Chassis Mount
- Yükseklik
- 17mm
- Configuration
- Single
- Current Collector Cutoff Max
- 5mA
- Montaj
- PCB, Screw
- Kurşunsuz Kodu
- no
- Max Power Dissipation
- 230W
- Pin Sayısı
- 24
- Uzunluk
- 107.5mm
- Input Capacitance Cies Vce
- 1.5nF @ 25V
- Genişlik
- 45mm
- Collectoremitter Breakdown Voltage
- 1.2kV
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Kılıf / Paket
- Module
- Turn On Time
- 110 ns
- Case Connection
- ISOLATED
- Number Of Elements
- 7
- RoHS Durumu
- RoHS Compliant
- Collector Emitter Voltage Vceo
- 1.2kV
- Halogen Free
- Not Halogen Free
- Terminal Sayısı
- 24
- Input
- Standard
- Yayın Yılı
- 2001
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Power Dissipation
- 230W
- Qualification Status
- Not Qualified
- Nem Hassasiyeti (MSL)
- Not Applicable
- Kurşunsuz
- Contains Lead
- Pin Sayısı
- 24
