Volume pricing
- 1+ pcs$34.22
- 10+ pcs$32.28
- 100+ pcs$30.46
- 500+ pcs$28.73
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Elements
- 7
- RoHS Durumu
- ROHS3 Compliant
- Turn On Time
- 37 ns
- Kılıf / Paket
- Module
- Case Connection
- ISOLATED
- Transistor Application
- POWER CONTROL
- Halogen Free
- Not Halogen Free
- Terminal Sayısı
- 23
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Qualification Status
- Not Qualified
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Input
- Standard
- Yayın Yılı
- 2002
- Parça Durumu
- Active
- Pin Sayısı
- 23
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Kurşunsuz
- Contains Lead
- Vceon Max Vge Ic
- 2V @ 15V, 20A
- Ntc Thermistor
- Yes
- Transistor Element Material
- SILICON
- ECCN Kodu
- EAR99
- Yüzey Montaj
- NO
- Voltage Collector Emitter Breakdown Max
- 600V
- Igbt Type
- Trench Field Stop
- Turn Off Timenom Toff
- 250 ns
- Polaritychannel Type
- N-CHANNEL
- Terminal Formu
- UNSPECIFIED
- Montaj Tipi
- Chassis Mount
- Configuration
- Three Phase Inverter
- Current Collector Cutoff Max
- 1mA
- Kurşunsuz Kodu
- no
- Currentcollector Ic Max
- 27A
- Fabrika Tedarik Süresi
- 16 Weeks
- Terminal Pozisyonu
- UPPER
- Power Max
- 94W
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Pin Sayısı
- 23
- Input Capacitance Cies Vce
- 1.1nF @ 25V
