Volume pricing
- 1+ pcs$25.65
- 10+ pcs$24.20
- 100+ pcs$22.83
- 500+ pcs$21.54
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Transistor Element Material
- SILICON
- Pin Sayısı
- 23
- Terminal Pozisyonu
- UPPER
- Yüzey Montaj
- NO
- Terminal Sayısı
- 23
- Input Capacitance Cies Vce
- 830pF @ 25V
- Kılıf / Paket
- Module
- Ntc Thermistor
- Yes
- Number Of Elements
- 7
- Transistor Application
- POWER CONTROL
- Power Max
- 81W
- Nem Hassasiyeti (MSL)
- Not Applicable
- Input
- Standard
- Terminal Formu
- UNSPECIFIED
- Voltage Collector Emitter Breakdown Max
- 600V
- Halogen Free
- Not Halogen Free
- Qualification Status
- Not Qualified
- Fabrika Tedarik Süresi
- 16 Weeks
- Currentcollector Ic Max
- 22A
- Kurşunsuz Kodu
- no
- ECCN Kodu
- EAR99
- Turn On Time
- 29 ns
- Vceon Max Vge Ic
- 2V @ 15V, 15A
- Kurşunsuz
- Contains Lead
- Yayın Yılı
- 2002
- Pin Sayısı
- 23
- Polaritychannel Type
- N-CHANNEL
- Çalışma Sıcaklığı
- -40°C~150°C
- Turn Off Timenom Toff
- 260 ns
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Case Connection
- ISOLATED
- RoHS Durumu
- RoHS Compliant
- Igbt Type
- Trench Field Stop
- Parça Durumu
- Active
- Configuration
- Three Phase Inverter
- Current Collector Cutoff Max
- 1mA
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Montaj Tipi
- Chassis Mount
