Volume pricing
- 1+ pcs$36.46
- 10+ pcs$34.40
- 100+ pcs$32.45
- 500+ pcs$30.62
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Case Connection
- ISOLATED
- RoHS Durumu
- RoHS Compliant
- Igbt Type
- Trench Field Stop
- Collectoremitter Breakdown Voltage
- 600V
- Parça Durumu
- Active
- Configuration
- Three Phase Inverter
- Current Collector Cutoff Max
- 1mA
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Montaj Tipi
- Chassis Mount
- Collector Emitter Voltage Vceo
- 600V
- Collectoremitter Saturation Voltage
- 2V
- Kurşunsuz
- Contains Lead
- Vceon Max Vge Ic
- 2V @ 15V, 10A
- Turn On Time
- 26 ns
- Power Dissipation
- 68W
- Yayın Yılı
- 2002
- Polaritychannel Type
- N-CHANNEL
- Pin Sayısı
- 23
- Reach Svhc
- No SVHC
- Çalışma Sıcaklığı
- -40°C~150°C
- Turn Off Timenom Toff
- 260 ns
- Montaj
- Screw
- Nem Hassasiyeti (MSL)
- Not Applicable
- Input
- Standard
- Terminal Formu
- UNSPECIFIED
- Halogen Free
- Not Halogen Free
- Qualification Status
- Not Qualified
- Fabrika Tedarik Süresi
- 16 Weeks
- Kurşunsuz Kodu
- no
- Max Collector Current
- 16A
- ECCN Kodu
- EAR99
- Max Power Dissipation
- 68W
- Pin Sayısı
- 23
- Transistor Element Material
- SILICON
- Terminal Pozisyonu
- UPPER
- Terminal Sayısı
- 23
- Input Capacitance Cies Vce
- 550pF @ 25V
- Kılıf / Paket
- Module
- Ntc Thermistor
- Yes
