Volume pricing
- 1+ pcs$346.65
- 10+ pcs$327.03
- 100+ pcs$308.52
- 500+ pcs$291.06
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Case Connection
- ISOLATED
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Igbt Type
- Trench Field Stop
- RoHS Durumu
- ROHS3 Compliant
- Collectoremitter Breakdown Voltage
- 1.2kV
- Seri
- PrimePack™2
- Parça Durumu
- Active
- Current Collector Cutoff Max
- 5mA
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Configuration
- Single
- Collector Emitter Voltage Vceo
- 1.2kV
- Collectoremitter Saturation Voltage
- 2.05V
- Montaj Tipi
- Chassis Mount
- Jesd30 Code
- R-XUFM-X7
- Vceon Max Vge Ic
- 2.05V @ 15V, 900A
- Yükseklik
- 38mm
- Turn On Time
- 350 ns
- Power Dissipation
- 5.1kW
- Yayın Yılı
- 2002
- Pin Sayısı
- 10
- Polaritychannel Type
- N-CHANNEL
- Genişlik
- 89mm
- Reach Svhc
- No SVHC
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Turn Off Timenom Toff
- 940 ns
- Montaj
- Screw
- Power Max
- 5100W
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Input
- Standard
- Terminal Formu
- UNSPECIFIED
- Voltage Collector Emitter Breakdown Max
- 1200V
- Qualification Status
- Not Qualified
- Fabrika Tedarik Süresi
- 10 Weeks
- Kurşunsuz Kodu
- no
- Max Collector Current
- 900A
- ECCN Kodu
- EAR99
- Element Configuration
- Dual
- Max Power Dissipation
- 5.1kW
- Terminal Pozisyonu
- UPPER
- Pin Sayısı
- 11
