Specifications
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Case Connection
- ISOLATED
- RoHS Durumu
- ROHS3 Compliant
- Igbt Type
- Trench Field Stop
- Parça Durumu
- Active
- Seri
- EconoDUAL™ 3
- Configuration
- Half Bridge
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Current Collector Cutoff Max
- 3mA
- Montaj Tipi
- Chassis Mount
- Jesd30 Code
- R-XUFM-X7
- Vceon Max Vge Ic
- 2.1V @ 15V, 600A
- Turn On Time
- 310 ns
- Yayın Yılı
- 2002
- Polaritychannel Type
- N-CHANNEL
- Çalışma Sıcaklığı
- -40°C~150°C
- Turn Off Timenom Toff
- 770 ns
- Power Max
- 20mW
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Collector Emitter Breakdown Max
- 1200V
- Input
- Standard
- Terminal Formu
- UNSPECIFIED
- Fabrika Tedarik Süresi
- 16 Weeks
- Currentcollector Ic Max
- 1200A
- ECCN Kodu
- EAR99
- Transistor Element Material
- SILICON
- Yüzey Montaj
- NO
- Terminal Pozisyonu
- UPPER
- Terminal Sayısı
- 7
- Input Capacitance Cies Vce
- 37nF @ 25V
- Kılıf / Paket
- Module
- Ntc Thermistor
- Yes
- Number Of Elements
- 2
- Transistor Application
- POWER CONTROL
