Specifications
- Input Capacitance Cies Vce
- 39nF @ 25V
- Terminal Sayısı
- 7
- Terminal Pozisyonu
- UPPER
- Yüzey Montaj
- NO
- Pin Sayısı
- 11
- Transistor Element Material
- SILICON
- Transistor Application
- POWER CONTROL
- Number Of Elements
- 2
- Ntc Thermistor
- Yes
- Kılıf / Paket
- Module
- Qualification Status
- Not Qualified
- Voltage Collector Emitter Breakdown Max
- 1200V
- Terminal Formu
- UNSPECIFIED
- Input
- Standard
- Vcesatmax
- 3.75 V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Power Max
- 3700W
- ECCN Kodu
- EAR99
- Gateemitter Voltagemax
- 20V
- Kurşunsuz Kodu
- no
- Currentcollector Ic Max
- 600A
- Yayın Yılı
- 2002
- Vceon Max Vge Ic
- 3.75V @ 15V, 600A
- Turn On Time
- 270 ns
- Jesd30 Code
- R-XUFM-X7
- Turn Off Timenom Toff
- 630 ns
- Çalışma Sıcaklığı
- -40°C~125°C
- Power Dissipationmax Abs
- 3700W
- Polaritychannel Type
- N-CHANNEL
- RoHS Durumu
- RoHS Compliant
- Case Connection
- ISOLATED
- REACH Uyumluluk Kodu
- compliant
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Montaj Tipi
- Chassis Mount
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Current Collector Cutoff Max
- 5mA
- Configuration
- 2 Independent
- Parça Durumu
- Obsolete
