Volume pricing
- 1+ pcs$313.31
- 10+ pcs$295.58
- 100+ pcs$278.85
- 500+ pcs$263.06
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Pozisyonu
- UPPER
- Yüzey Montaj
- NO
- Pin Sayısı
- 11
- Transistor Element Material
- SILICON
- Terminal Sayısı
- 7
- Input Capacitance Cies Vce
- 37nF @ 25V
- Kılıf / Paket
- Module
- Number Of Elements
- 2
- Ntc Thermistor
- Yes
- Transistor Application
- POWER CONTROL
- Power Max
- 3350W
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Input
- Standard
- Terminal Formu
- UNSPECIFIED
- Voltage Collector Emitter Breakdown Max
- 1200V
- Halogen Free
- Not Halogen Free
- Vcesatmax
- 2.05 V
- Qualification Status
- Not Qualified
- Currentcollector Ic Max
- 600A
- Fabrika Tedarik Süresi
- 14 Weeks
- Kurşunsuz Kodu
- no
- ECCN Kodu
- EAR99
- Element Configuration
- Dual
- Gateemitter Voltagemax
- 20V
- Jesd30 Code
- R-XUFM-X7
- Kurşunsuz
- Contains Lead
- Vceon Max Vge Ic
- 2.05V @ 15V, 600A
- Turn On Time
- 410 ns
- Yayın Yılı
- 2002
- Pin Sayısı
- 10
- Polaritychannel Type
- N-CHANNEL
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Turn Off Timenom Toff
- 1020 ns
- Power Dissipationmax Abs
- 3350W
- Case Connection
- ISOLATED
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Igbt Type
- Trench Field Stop
- RoHS Durumu
- ROHS3 Compliant
- Parça Durumu
- Active
- Current Collector Cutoff Max
- 5mA
