Volume pricing
- 1+ pcs$220.14
- 10+ pcs$207.68
- 100+ pcs$195.92
- 500+ pcs$184.83
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj Tipi
- Chassis Mount
- Current Collector Cutoff Max
- 1mA
- Configuration
- Half Bridge Inverter
- Seri
- C
- Parça Durumu
- Active
- Igbt Type
- Trench Field Stop
- RoHS Durumu
- ROHS3 Compliant
- Case Connection
- ISOLATED
- Turn Off Timenom Toff
- 890 ns
- Çalışma Sıcaklığı
- -40°C~150°C
- Yayın Yılı
- 2002
- Turn On Time
- 310 ns
- Vceon Max Vge Ic
- 2.3V @ 15V, 500A
- Jesd30 Code
- R-XUFM-X7
- ECCN Kodu
- EAR99
- Currentcollector Ic Max
- 500A
- Fabrika Tedarik Süresi
- 40 Weeks
- Voltage Collector Emitter Breakdown Max
- 1700V
- Input
- Standard
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Elements
- 2
- Ntc Thermistor
- No
- Kılıf / Paket
- Module
- Input Capacitance Cies Vce
- 45nF @ 25V
- Terminal Sayısı
- 7
- Terminal Pozisyonu
- UPPER
- Yüzey Montaj
- NO
