Volume pricing
- 1+ pcs$123.92
- 10+ pcs$116.91
- 100+ pcs$110.29
- 500+ pcs$104.05
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Kılıf / Paket
- Module
- Polaritychannel Type
- N-CHANNEL
- Vceon Max Vge Ic
- 2.1V @ 15V, 450A
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Configuration
- 2 Independent
- Yüzey Montaj
- NO
- Continuous Collector Current
- 450A
- Case Connection
- ISOLATED
- Max Junction Temperature Tj
- 150°C
- Çalışma Sıcaklığı
- -40°C~150°C
- Turn On Delay Time
- 190 ns
- Collector Emitter Voltage Vceo
- 1.2kV
- Jesd30 Code
- R-XUFM-X11
- RoHS Durumu
- RoHS Compliant
- Current Collector Cutoff Max
- 3mA
- Turn Off Delay Time
- 490 ns
- Yayın Yılı
- 2002
- Number Of Elements
- 2
- Parça Durumu
- Active
- Terminal Pozisyonu
- UPPER
- Turn Off Timenom Toff
- 740 ns
- Igbt Type
- Trench Field Stop
- Transistor Element Material
- SILICON
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Terminal Formu
- UNSPECIFIED
- Voltage Collector Emitter Breakdown Max
- 1200V
- Montaj Tipi
- Chassis Mount
- Fabrika Tedarik Süresi
- 16 Weeks
- Input
- Standard
- Yükseklik
- 17.5mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Turn On Time
- 290 ns
- Terminal Sayısı
- 11
- Input Capacitance Cies Vce
- 28nF @ 25V
- Ntc Thermistor
- Yes
- Collectoremitter Saturation Voltage
- 1.75V
