Specifications
- Yüzey Montaj
- NO
- Configuration
- 2 Independent
- Case Connection
- ISOLATED
- Çalışma Sıcaklığı
- -40°C~150°C
- ECCN Kodu
- EAR99
- Transistor Application
- POWER CONTROL
- Kılıf / Paket
- Module
- Vceon Max Vge Ic
- 2.3V @ 15V, 300A
- Pin Sayısı
- 7
- Number Of Elements
- 2
- Gateemitter Voltagemax
- 20V
- Polarity
- NPN
- Element Configuration
- Dual
- RoHS Durumu
- RoHS Compliant
- Jesd30 Code
- R-XUFM-X5
- Yayın Yılı
- 2002
- Vcesatmax
- 2.3 V
- Current Collector Cutoff Max
- 1mA
- Pin Sayısı
- 7
- Fabrika Tedarik Süresi
- 14 Weeks
- Power Max
- 1800W
- Input
- Standard
- Montaj Tipi
- Chassis Mount
- Parça Durumu
- Active
- Turn Off Timenom Toff
- 930 ns
- Terminal Pozisyonu
- UPPER
- Igbt Type
- Trench Field Stop
- Transistor Element Material
- SILICON
- Voltage Collector Emitter Breakdown Max
- 1700V
- Kurşunsuz
- Lead Free
- Terminal Formu
- UNSPECIFIED
- Currentcollector Ic Max
- 440A
- Ntc Thermistor
- No
- Halogen Free
- Not Halogen Free
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Turn On Time
- 355 ns
- Power Dissipationmax Abs
- 1800W
- Input Capacitance Cies Vce
- 24.5nF @ 25V
- Terminal Sayısı
- 5
