Volume pricing
- 1+ pcs$102.28
- 10+ pcs$96.49
- 100+ pcs$91.03
- 500+ pcs$85.88
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Turn On Time
- 325 ns
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Input Capacitance Cies Vce
- 19nF @ 25V
- Terminal Sayısı
- 7
- Currentcollector Ic Max
- 460A
- Halogen Free
- Not Halogen Free
- Ntc Thermistor
- Yes
- Kurşunsuz Kodu
- yes
- Transistor Element Material
- SILICON
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Igbt Type
- Trench Field Stop
- Parça Durumu
- Active
- Turn Off Timenom Toff
- 800 ns
- Terminal Pozisyonu
- UPPER
- Kurşunsuz
- Lead Free
- Voltage Collector Emitter Breakdown Max
- 1200V
- Terminal Formu
- UNSPECIFIED
- Input
- Standard
- Fabrika Tedarik Süresi
- 14 Weeks
- Power Max
- 1600W
- Montaj Tipi
- Chassis Mount
- RoHS Durumu
- RoHS Compliant
- Element Configuration
- Dual
- Yayın Yılı
- 2002
- Pin Sayısı
- 7
- Current Collector Cutoff Max
- 5mA
- Pin Sayısı
- 7
- Number Of Elements
- 2
- Polarity
- NPN
- ECCN Kodu
- EAR99
- Kılıf / Paket
- Module
- Vceon Max Vge Ic
- 2.15V @ 15V, 300A
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Case Connection
- ISOLATED
- Configuration
- 2 Independent
- Yüzey Montaj
- NO
- Qualification Status
- Not Qualified
- Çalışma Sıcaklığı
- -40°C~150°C
