Specifications
- Terminal Formu
- UNSPECIFIED
- Tedarikçi Cihaz Paketi
- Module
- REACH Uyumluluk Kodu
- compliant
- Voltage Collector Emitter Breakdown Max
- 1200V
- Transistor Element Material
- SILICON
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Igbt Type
- Trench Field Stop
- Parça Durumu
- Obsolete
- Turn Off Timenom Toff
- 600 ns
- Terminal Pozisyonu
- UPPER
- Montaj Tipi
- Chassis Mount
- Input
- Standard
- Power Max
- 1050W
- Terminal Sayısı
- 10
- Input Capacitance Cies Vce
- 14nF @ 25V
- Turn On Time
- 190 ns
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- no
- Ntc Thermistor
- Yes
- Polaritychannel Type
- N-CHANNEL
- Vceon Max Vge Ic
- 2.15V @ 15V, 200A
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Kılıf / Paket
- Module
- ECCN Kodu
- EAR99
- Çalışma Sıcaklığı
- -40°C~150°C
- Qualification Status
- Not Qualified
- Case Connection
- ISOLATED
- Yüzey Montaj
- NO
- Configuration
- 2 Independent
- Current Collector Cutoff Max
- 1mA
- Yayın Yılı
- 2002
- Jesd30 Code
- R-XUFM-X10
- RoHS Durumu
- RoHS Compliant
- Number Of Elements
- 2
- Pin Sayısı
- 10
