Volume pricing
- 1+ pcs$140.28
- 10+ pcs$132.34
- 100+ pcs$124.85
- 500+ pcs$117.78
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 20 Weeks
- Power Max
- 1400W
- Input
- Standard
- Montaj Tipi
- Chassis Mount
- Parça Durumu
- Active
- Turn Off Timenom Toff
- 590 ns
- Terminal Pozisyonu
- UPPER
- Transistor Element Material
- SILICON
- Voltage Collector Emitter Breakdown Max
- 1200V
- Terminal Formu
- UNSPECIFIED
- Ntc Thermistor
- No
- Kurşunsuz Kodu
- yes
- Collectoremitter Breakdown Voltage
- 1.2kV
- Additional Feature
- FAST
- Collectoremitter Saturation Voltage
- 3.2V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Turn On Time
- 180 ns
- Input Capacitance Cies Vce
- 13nF @ 25V
- Terminal Sayısı
- 7
- Configuration
- 2 Independent
- Case Connection
- ISOLATED
- Collector Emitter Voltage Vceo
- 1.2kV
- Power Dissipation
- 1.4kW
- Çalışma Sıcaklığı
- -40°C~125°C
- ECCN Kodu
- EAR99
- Montaj
- Screw
- Kılıf / Paket
- Module
- Vceon Max Vge Ic
- 3.7V @ 15V, 200A
- Polaritychannel Type
- N-CHANNEL
- Pin Sayısı
- 7
- Number Of Elements
- 2
- Element Configuration
- Dual
- Max Collector Current
- 275A
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2002
- Current Collector Cutoff Max
- 5mA
- Pin Sayısı
- 7
