Volume pricing
- 1+ pcs$44.60
- 10+ pcs$42.08
- 100+ pcs$39.70
- 500+ pcs$37.45
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yayın Yılı
- 2002
- Vceon Max Vge Ic
- 2.15V @ 15V, 150A
- Input
- Standard
- Max Power Dissipation
- 625W
- Kurşunsuz
- Contains Lead
- Uzunluk
- 55.9mm
- Yükseklik
- 17mm
- Max Collector Current
- 200A
- Collector Emitter Voltage Vceo
- 1.2kV
- Montaj
- PCB, Screw
- Montaj Tipi
- Chassis Mount
- Polaritychannel Type
- N-CHANNEL
- Input Capacitance Cies Vce
- 10.5nF @ 25V
- Kılıf / Paket
- Module
- ECCN Kodu
- EAR99
- Configuration
- 2 Independent
- Voltage Collector Emitter Breakdown Max
- 1200V
- Element Configuration
- Dual
- Genişlik
- 45.6mm
- Turn Off Timenom Toff
- 610 ns
- Parça Durumu
- Not For New Designs
- Fabrika Tedarik Süresi
- 14 Weeks
- Power Max
- 625W
- RoHS Durumu
- RoHS Compliant
- Transistor Element Material
- SILICON
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Nem Hassasiyeti (MSL)
- Not Applicable
- Qualification Status
- Not Qualified
- Number Of Elements
- 2
- Çalışma Sıcaklığı
- -40°C~125°C
- Terminal Sayısı
- 24
- Terminal Pozisyonu
- UPPER
- Kurşunsuz Kodu
- no
- Case Connection
- ISOLATED
- Halogen Free
- Not Halogen Free
- Current Collector Cutoff Max
- 1mA
- Pin Sayısı
- 2
- Terminal Formu
- UNSPECIFIED
- Pin Sayısı
- 24
- Turn On Time
- 330 ns
