Volume pricing
- 1+ pcs$1.00
- 10+ pcs$1.00
- 25+ pcs$993.79
- 50+ pcs$986.88
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Sayısı
- 12
- Terminal Pozisyonu
- UPPER
- Çalışma Sıcaklığı
- -40°C~150°C
- Transistor Application
- POWER CONTROL
- Number Of Elements
- 2
- Current Collector Cutoff Max
- 5mA
- Case Connection
- ISOLATED
- Terminal Formu
- UNSPECIFIED
- Igbt Type
- Trench Field Stop
- Turn On Time
- 1030 ns
- Jesd30 Code
- R-PUFM-X12
- Ntc Thermistor
- Yes
- Currentcollector Ic Max
- 1400A
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Max Collector Current
- 1.4kA
- Input
- Standard
- Yayın Yılı
- 2007
- Vceon Max Vge Ic
- 2.2V @ 15V, 1400A
- Input Capacitance Cies Vce
- 110nF @ 25V
- Polaritychannel Type
- N-CHANNEL
- Montaj Tipi
- Chassis Mount
- Montaj
- Screw
- Collector Emitter Voltage Vceo
- 1.7kV
- Turn Off Timenom Toff
- 2190 ns
- Additional Feature
- UL APPROVED
- Configuration
- 2 Independent
- Element Configuration
- Dual
- Voltage Collector Emitter Breakdown Max
- 1700V
- ECCN Kodu
- EAR99
- Kılıf / Paket
- Module
- Nem Hassasiyeti (MSL)
- Not Applicable
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Transistor Element Material
- SILICON
- RoHS Durumu
- RoHS Compliant
- Fabrika Tedarik Süresi
- 50 Weeks
- Parça Durumu
- Active
