Volume pricing
- 1+ pcs$666.82
- 10+ pcs$629.08
- 100+ pcs$593.47
- 500+ pcs$559.87
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Configuration
- 2 Independent
- Element Configuration
- Dual
- Voltage Collector Emitter Breakdown Max
- 1700V
- Turn Off Timenom Toff
- 2190 ns
- Kılıf / Paket
- Module
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Transistor Element Material
- SILICON
- Qualification Status
- Not Qualified
- Parça Durumu
- Active
- Power Max
- 955000W
- Fabrika Tedarik Süresi
- 50 Weeks
- Input
- Standard
- Power Dissipation
- 9.55kW
- Kurşunsuz
- Lead Free
- Yayın Yılı
- 2002
- Vceon Max Vge Ic
- 2.2V @ 15V, 1400A
- Input Capacitance Cies Vce
- 110nF @ 25V
- Polaritychannel Type
- N-CHANNEL
- Seri
- PrimePACK™3
- Collector Emitter Voltage Vceo
- 1.7kV
- Montaj
- Screw
- Montaj Tipi
- Chassis Mount
- Terminal Formu
- UNSPECIFIED
- Igbt Type
- Trench Field Stop
- Turn On Time
- 1030 ns
- Pin Sayısı
- 12
- Pin Sayısı
- 12
- Currentcollector Ic Max
- 1400A
- Ntc Thermistor
- Yes
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Çalışma Sıcaklığı
- -40°C~150°C
- Terminal Sayısı
- 12
- Terminal Pozisyonu
- UPPER
- Number Of Elements
- 2
- Collectoremitter Saturation Voltage
- 2.2V
- Transistor Application
- POWER CONTROL
- Case Connection
- ISOLATED
