Volume pricing
- 1+ pcs$573.02
- 10+ pcs$540.58
- 100+ pcs$509.99
- 500+ pcs$481.12
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- ECCN Kodu
- EAR99
- Kılıf / Paket
- Module
- Turn Off Timenom Toff
- 1890 ns
- Additional Feature
- UL APPROVED
- Configuration
- 2 Independent
- Voltage Collector Emitter Breakdown Max
- 1700V
- Element Configuration
- Dual
- Power Max
- 1000000W
- Fabrika Tedarik Süresi
- 10 Weeks
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Transistor Element Material
- SILICON
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2007
- Vceon Max Vge Ic
- 2.45V @ 15V, 1000A
- Max Collector Current
- 1.39kA
- Input
- Standard
- Montaj Tipi
- Chassis Mount
- Montaj
- Screw
- Collector Emitter Voltage Vceo
- 1.7kV
- Input Capacitance Cies Vce
- 81nF @ 25V
- Polaritychannel Type
- N-CHANNEL
- Pin Sayısı
- 10
- Terminal Formu
- UNSPECIFIED
- Turn On Time
- 720 ns
- Igbt Type
- Trench Field Stop
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Jesd30 Code
- R-PUFM-X12
- Ntc Thermistor
- Yes
- Currentcollector Ic Max
- 1000A
- Transistor Application
- POWER CONTROL
- Number Of Elements
- 2
- Terminal Sayısı
- 12
- Terminal Pozisyonu
- UPPER
- Çalışma Sıcaklığı
- -40°C~150°C
- Current Collector Cutoff Max
- 5mA
- Case Connection
- ISOLATED
