Volume pricing
- 1+ pcs$1.00
- 10+ pcs$1.00
- 25+ pcs$1.00
- 50+ pcs$1.00
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Transistor Element Material
- SILICON
- Voltage Collector Emitter Breakdown Max
- 3300V
- Turn Off Timenom Toff
- 3550 ns
- Configuration
- Dual Brake Chopper
- Polaritychannel Type
- N-CHANNEL
- Pin Sayısı
- 9
- Fabrika Tedarik Süresi
- 12 Weeks
- Kılıf / Paket
- Module
- Input
- Standard
- Terminal Formu
- UNSPECIFIED
- Current Collector Cutoff Max
- 5mA
- Ntc Thermistor
- No
- Case Connection
- ISOLATED
- Vceon Max Vge Ic
- 3.1V @ 15V, 1000A
- Kurşunsuz
- Contains Lead
- Terminal Sayısı
- 9
- Turn On Time
- 1150 ns
- Montaj
- Screw
- Halogen Free
- Not Halogen Free
- RoHS Durumu
- RoHS Compliant
- Collector Emitter Voltage Vceo
- 3.3kV
- Yayın Yılı
- 2002
- Montaj Tipi
- Chassis Mount
- Number Of Elements
- 2
- Input Capacitance Cies Vce
- 190nF @ 25V
- Igbt Type
- Trench Field Stop
- Element Configuration
- Dual
- Currentcollector Ic Max
- 1000A
- Nem Hassasiyeti (MSL)
- Not Applicable
- Çalışma Sıcaklığı
- -40°C~150°C
- Max Collector Current
- 1kA
- Terminal Pozisyonu
- UPPER
- Power Max
- 11500W
- Parça Durumu
- Active
- Transistor Application
- POWER CONTROL
