Volume pricing
- 1+ pcs$27.50
- 10+ pcs$25.95
- 100+ pcs$24.48
- 500+ pcs$23.09
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Current Collector Cutoff Max
- 1mA
- Qualification Status
- Not Qualified
- Pin Sayısı
- 23
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Halogen Free
- Not Halogen Free
- Yükseklik
- 12mm
- Ntc Thermistor
- Yes
- Turn On Time
- 37 ns
- Kurşunsuz Kodu
- no
- Input
- Standard
- Number Of Elements
- 6
- Polaritychannel Type
- N-CHANNEL
- Max Collector Current
- 29A
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -40°C~150°C
- Configuration
- Three Phase Inverter
- Pin Sayısı
- 23
- Kurşunsuz
- Contains Lead
- Input Capacitance Cies Vce
- 1.1nF @ 25V
- Turn Off Timenom Toff
- 250 ns
- Terminal Sayısı
- 23
- RoHS Durumu
- RoHS Compliant
- Nem Hassasiyeti (MSL)
- Not Applicable
- Max Power Dissipation
- 94W
- Collector Emitter Voltage Vceo
- 600V
- Fabrika Tedarik Süresi
- 16 Weeks
- Yayın Yılı
- 2002
- Montaj
- PCB
- Igbt Type
- Trench Field Stop
- ECCN Kodu
- EAR99
- Currentcollector Ic Max
- 29A
- Vceon Max Vge Ic
- 2V @ 15V, 20A
- Case Connection
- ISOLATED
- Terminal Pozisyonu
- UPPER
- Genişlik
- 33.8mm
- Kılıf / Paket
- Module
- Montaj Tipi
- Chassis Mount
- Transistor Element Material
- SILICON
- Terminal Formu
- UNSPECIFIED
