Volume pricing
- 1+ pcs$34.43
- 10+ pcs$32.48
- 100+ pcs$30.64
- 500+ pcs$28.91
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yüzey Montaj
- NO
- Kılıf / Paket
- Module
- Transistor Application
- POWER CONTROL
- Terminal Sayısı
- 11
- Transistor Element Material
- SILICON
- Kurşunsuz
- Contains Lead
- Çalışma Sıcaklığı
- -40°C~150°C
- Voltage Collector Emitter Breakdown Max
- 600V
- Terminal Pozisyonu
- UPPER
- Polaritychannel Type
- N-CHANNEL
- Power Max
- 275W
- Current Collector Cutoff Max
- 1mA
- Currentcollector Ic Max
- 100A
- Input
- Standard
- Parça Durumu
- Active
- Number Of Elements
- 4
- Fabrika Tedarik Süresi
- 16 Weeks
- Turn On Time
- 45 ns
- Jesd30 Code
- R-XUFM-X11
- Ntc Thermistor
- Yes
- ECCN Kodu
- EAR99
- Vceon Max Vge Ic
- 1.9V @ 15V, 75A
- Montaj Tipi
- Chassis Mount
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Yayın Yılı
- 2002
- Turn Off Timenom Toff
- 330 ns
- RoHS Durumu
- RoHS Compliant
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Case Connection
- ISOLATED
- Terminal Formu
- UNSPECIFIED
- Input Capacitance Cies Vce
- 4.6nF @ 25V
- Halogen Free
- Not Halogen Free
- Configuration
- Three Phase Inverter
- Igbt Type
- Trench Field Stop
- Nem Hassasiyeti (MSL)
- Not Applicable
- Pin Sayısı
- 15
