Volume pricing
- 1+ pcs$142.60
- 10+ pcs$134.53
- 100+ pcs$126.92
- 500+ pcs$119.73
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Sayısı
- 20
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Ntc Thermistor
- Yes
- Vceon Max Vge Ic
- 1.75V @ 15V, 280A
- Voltage Collector Emitter Breakdown Max
- 650V
- Transistor Application
- POWER CONTROL
- Input Capacitance Cies Vce
- 18.5nF @ 25V
- Case Connection
- ISOLATED
- Turn Off Timenom Toff
- 600 ns
- Yayın Yılı
- 2002
- Terminal Pozisyonu
- UPPER
- Igbt Type
- Trench Field Stop
- Turn On Time
- 190 ns
- Polaritychannel Type
- N-CHANNEL
- Jesd30 Code
- R-XUFM-X20
- ECCN Kodu
- EAR99
- Number Of Elements
- 4
- Çalışma Sıcaklığı
- -40°C~150°C
- Currentcollector Ic Max
- 300A
- Fabrika Tedarik Süresi
- 14 Weeks
- Seri
- EconoPACK™ 4
- Input
- Standard
- Kılıf / Paket
- Module
- Terminal Formu
- UNSPECIFIED
- Yüzey Montaj
- NO
- Transistor Element Material
- SILICON
- Current Collector Cutoff Max
- 1mA
- Power Max
- 20mW
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- ROHS3 Compliant
- Montaj Tipi
- Chassis Mount
- Configuration
- Full Bridge
- Parça Durumu
- Active
