Volume pricing
- 1+ pcs$108.10
- 10+ pcs$101.98
- 100+ pcs$96.21
- 500+ pcs$90.76
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Igbt Type
- Trench Field Stop
- Jesd30 Code
- R-XUFM-X20
- Polaritychannel Type
- N-CHANNEL
- Turn On Time
- 190 ns
- Terminal Pozisyonu
- UPPER
- Yayın Yılı
- 2002
- Case Connection
- ISOLATED
- Input Capacitance Cies Vce
- 12.5nF @ 25V
- Turn Off Timenom Toff
- 600 ns
- Number Of Elements
- 4
- ECCN Kodu
- EAR99
- Halogen Free
- Not Halogen Free
- Terminal Sayısı
- 20
- Kurşunsuz Kodu
- no
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Voltage Collector Emitter Breakdown Max
- 650V
- Transistor Application
- POWER CONTROL
- Vceon Max Vge Ic
- 1.95V @ 15V, 200A
- Kurşunsuz
- Contains Lead
- Ntc Thermistor
- Yes
- Configuration
- Three Phase Inverter
- Montaj Tipi
- Chassis Mount
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- RoHS Compliant
- Pin Sayısı
- 20
- Parça Durumu
- Active
- Input
- Standard
- Kılıf / Paket
- Module
- Currentcollector Ic Max
- 200A
- Çalışma Sıcaklığı
- -40°C~150°C
- Fabrika Tedarik Süresi
- 16 Weeks
- Power Max
- 680W
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Current Collector Cutoff Max
- 1mA
- Transistor Element Material
- SILICON
- Terminal Formu
- UNSPECIFIED
- Yüzey Montaj
- NO
