Volume pricing
- 1+ pcs$112.80
- 10+ pcs$106.42
- 100+ pcs$100.40
- 500+ pcs$94.71
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj Tipi
- Chassis Mount
- Kurşunsuz
- Contains Lead
- Nem Hassasiyeti (MSL)
- Not Applicable
- Kılıf / Paket
- Module
- Transistor Element Material
- SILICON
- Vceon Max Vge Ic
- 2.15V @ 15V, 25A
- Terminal Formu
- UNSPECIFIED
- Turn On Time
- 55 ns
- Halogen Free
- Not Halogen Free
- Case Connection
- ISOLATED
- ECCN Kodu
- EAR99
- Voltage Collector Emitter Breakdown Max
- 1200V
- Input Capacitance Cies Vce
- 1.45nF @ 25V
- Power Max
- 160W
- Yükseklik
- 17mm
- Configuration
- Three Phase Inverter
- Montaj
- PCB, Screw
- Current Collector Cutoff Max
- 1mA
- Max Collector Current
- 25A
- Terminal Pozisyonu
- UPPER
- Max Power Dissipation
- 160W
- Terminal Sayısı
- 38
- Igbt Type
- Trench Field Stop
- Uzunluk
- 122mm
- Additional Feature
- UL RECOGNIZED
- Input
- Standard
- Yayın Yılı
- 2002
- Pin Sayısı
- 38
- Number Of Elements
- 12
- RoHS Durumu
- RoHS Compliant
- Çalışma Sıcaklığı
- -40°C~150°C
- Ntc Thermistor
- No
- Transistor Application
- POWER CONTROL
- Turn Off Timenom Toff
- 470 ns
- Fabrika Tedarik Süresi
- 16 Weeks
- Collector Emitter Voltage Vceo
- 1.2kV
- Genişlik
- 62mm
- Polaritychannel Type
- N-CHANNEL
- Parça Durumu
- Active
