Volume pricing
- 1+ pcs$118.11
- 10+ pcs$111.42
- 100+ pcs$105.11
- 500+ pcs$99.16
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Case Connection
- ISOLATED
- Halogen Free
- Not Halogen Free
- Terminal Pozisyonu
- UPPER
- Operating Temperature Junction
- -40°C~125°C
- Forward Current
- 800A
- Number Of Elements
- 1
- Rep Pk Reverse Voltagemax
- 1700V
- Kurşunsuz
- Lead Free
- Ambalaj
- Tray
- Parça Durumu
- Active
- Terminal Sayısı
- 5
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Diode Type
- Standard
- Montaj Tipi
- Chassis Mount
- Yayın Yılı
- 2002
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Configuration
- SINGLE
- Jesd30 Code
- R-XUFM-X5
- Kurşunsuz Kodu
- yes
- HTS Kodu
- 8541.10.00.80
- Kılıf / Paket
- Module
- Voltage Forward Vf Max If
- 2.2V @ 800A
- Yüzey Montaj
- NO
- Applications
- GENERAL PURPOSE
- Speed
- Standard Recovery >500ns, > 200mA (Io)
- Pin Sayısı
- 5
- Voltage Dc Reverse Vr Max
- 1700V
- Terminal Formu
- UNSPECIFIED
- ECCN Kodu
- EAR99
- Number Of Phases
- 1
- Diode Element Material
- SILICON
- Qualification Status
- Not Qualified
- RoHS Durumu
- RoHS Compliant
- Current Reverse Leakage Vr
- 780A @ 900V
