Specifications
- Reference Standard
- IEC-747-6
- Jesd30 Code
- R-XUFM-X5
- ECCN Kodu
- EAR99
- Trigger Device Type
- SCR
- Max Repetitive Reverse Voltage Vrrm
- 1.2kV
- Current Non Rep Surge5060hz Itsm
- 4800A @ 50Hz
- Terminal Formu
- UNSPECIFIED
- Yükseklik
- 30mm
- Montaj Tipi
- Chassis Mount
- Configuration
- SINGLE WITH BUILT-IN DIODE
- Montaj
- Panel, Screw
- Fabrika Tedarik Süresi
- 4 Weeks
- Terminal Pozisyonu
- UPPER
- Max Forward Surge Current Ifsm
- 4.1kA
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Additional Feature
- UL RECOGNIZED
- Structure
- Series Connection - All SCRs
- Uzunluk
- 94mm
- Pin Sayısı
- 142
- HTS Kodu
- 8541.30.00.80
- Genişlik
- 34mm
- Number Of Elements
- 1
- RoHS Durumu
- RoHS Compliant
- Kılıf / Paket
- Module
- Case Connection
- ISOLATED
- Hold Current
- 200mA
- Output Current
- 230A
- Halogen Free
- Not Halogen Free
- Current On State It Av Max
- 142A
- Terminal Sayısı
- 5
- Reverse Voltage
- 1.2kV
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Nem Hassasiyeti (MSL)
- Not Applicable
- Ambalaj
- Bulk
- Repetitive Peak Offstate Voltage
- 1200V
- Voltage Gate Trigger Vgt Max
- 2V
- Current Gate Trigger Igt Max
- 150mA
- Number Of Scrsdiodes
- 2 SCRs
- Yayın Yılı
- 2003
- Parça Durumu
- Obsolete
