Volume pricing
- 1+ pcs$319.45
- 10+ pcs$301.37
- 100+ pcs$284.31
- 500+ pcs$268.21
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Turn Off Timenom Toff
- 1300 ns
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Çalışma Sıcaklığı
- -40°C~150°C
- Yayın Yılı
- 2002
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Currentcollector Ic Max
- 900A
- ECCN Kodu
- EAR99
- Power Max
- 5100W
- Configuration
- Single Chopper
- Halogen Free
- Not Halogen Free
- Element Configuration
- Single
- Terminal Pozisyonu
- UPPER
- Case Connection
- ISOLATED
- Turn On Time
- 370 ns
- Pin Sayısı
- 10
- Collectoremitter Breakdown Voltage
- 1.2kV
- Number Of Elements
- 1
- Collector Emitter Voltage Vceo
- 1.2kV
- Transistor Application
- POWER CONTROL
- Max Power Dissipation
- 5.1kW
- Reach Svhc
- No SVHC
- Input
- Standard
- Kılıf / Paket
- Module
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Montaj Tipi
- Chassis Mount
- Voltage Collector Emitter Breakdown Max
- 1200V
- Montaj
- Screw
- Vceon Max Vge Ic
- 2.05V @ 15V, 900A
- Jesd30 Code
- R-XUFM-X6
- Current Collector Cutoff Max
- 5mA
- Ntc Thermistor
- Yes
- Igbt Type
- Trench Field Stop
- Polaritychannel Type
- N-CHANNEL
- Parça Durumu
- Active
- Qualification Status
- Not Qualified
- Kurşunsuz Kodu
- no
- Kurşunsuz
- Contains Lead
- Terminal Formu
- UNSPECIFIED
- Terminal Sayısı
- 6
- Pin Sayısı
- 10
