Volume pricing
- 1+ pcs$57.05
- 10+ pcs$53.82
- 100+ pcs$50.78
- 500+ pcs$47.90
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Montaj Tipi
- Chassis Mount
- Kılıf / Paket
- Module
- Jesd30 Code
- R-XUFM-X22
- Current Collector Cutoff Max
- 1mA
- Vceon Max Vge Ic
- 1.7V @ 15V, 20A
- Voltage Collector Emitter Breakdown Max
- 1200V
- Seri
- EconoPACK™2
- Parça Durumu
- Active
- Polaritychannel Type
- N-CHANNEL
- Igbt Type
- Trench Field Stop
- Ntc Thermistor
- Yes
- Transistor Element Material
- SILICON
- Input Capacitance Cies Vce
- 2.35nF @ 25V
- RoHS Durumu
- ROHS3 Compliant
- Terminal Formu
- UNSPECIFIED
- Terminal Sayısı
- 22
- Currentcollector Ic Max
- 20A
- Yayın Yılı
- 2002
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- ECCN Kodu
- EAR99
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Turn Off Timenom Toff
- 375 ns
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Configuration
- Half Bridge
- Power Max
- 20mW
- Turn On Time
- 40 ns
- Case Connection
- ISOLATED
- Yüzey Montaj
- NO
- Terminal Pozisyonu
- UPPER
- Transistor Application
- POWER CONTROL
- Input
- Standard
- Fabrika Tedarik Süresi
- 16 Weeks
- Number Of Elements
- 2
