Volume pricing
- 1+ pcs$442.89
- 10+ pcs$417.82
- 100+ pcs$394.17
- 500+ pcs$371.86
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Current Collector Cutoff Max
- 5mA
- Terminal Formu
- UNSPECIFIED
- Terminal Pozisyonu
- UPPER
- Input Capacitance Cies Vce
- 82nF @ 25V
- Montaj Tipi
- Chassis Mount
- Voltage Collector Emitter Breakdown Max
- 1200V
- Vceon Max Vge Ic
- 2.1V @ 15V, 1400A
- Yüzey Montaj
- NO
- Turn On Time
- 340 ns
- Qualification Status
- Not Qualified
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Polaritychannel Type
- N-CHANNEL
- Case Connection
- ISOLATED
- Transistor Application
- POWER CONTROL
- Terminal Sayısı
- 6
- Turn Off Timenom Toff
- 1200 ns
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -40°C~150°C
- Power Max
- 7700W
- Pin Sayısı
- 12
- Configuration
- Single Chopper
- RoHS Durumu
- RoHS Compliant
- Jesd30 Code
- R-XUFM-X6
- Yayın Yılı
- 2002
- Igbt Type
- Trench Field Stop
- Number Of Elements
- 1
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Transistor Element Material
- SILICON
- Ntc Thermistor
- Yes
- Kurşunsuz Kodu
- no
- Input
- Standard
- Kılıf / Paket
- Module
- Currentcollector Ic Max
- 1400A
- REACH Uyumluluk Kodu
- compliant
