Volume pricing
- 1+ pcs$53.22
- 10+ pcs$50.21
- 100+ pcs$47.36
- 500+ pcs$44.68
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Turn On Time
- 137 ns
- Terminal Sayısı
- 27
- Max Repetitive Reverse Voltage Vrrm
- 1.6kV
- Number Of Elements
- 1
- Uzunluk
- 48mm
- Terminal Pozisyonu
- UPPER
- Transistor Application
- POWER CONTROL
- Kurşunsuz Kodu
- no
- Pin Sayısı
- 27
- Power Max
- 335W
- Parça Durumu
- Active
- Montaj Tipi
- Chassis Mount
- Collector Emitter Voltage Vceo
- 1.2kV
- Yükseklik
- 12mm
- Genişlik
- 33.8mm
- Fabrika Tedarik Süresi
- 16 Weeks
- Kılıf / Paket
- Module
- Input Capacitance Cies Vce
- 2.8nF @ 25V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Peak Reverse Current
- 1mA
- Jesd30 Code
- R-XUFM-X27
- Yayın Yılı
- 2006
- Qualification Status
- Not Qualified
- Input
- Standard
- Transistor Element Material
- SILICON
- Çalışma Sıcaklığı
- -40°C~150°C
- Turn Off Timenom Toff
- 630 ns
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Ntc Thermistor
- Yes
- Terminal Formu
- UNSPECIFIED
- Element Configuration
- Single
- RoHS Durumu
- RoHS Compliant
- Pin Sayısı
- 10
- Voltage Collector Emitter Breakdown Max
- 1200V
- Forward Current
- 65A
- Case Connection
- ISOLATED
- Configuration
- Three Phase Inverter
- Max Collector Current
- 69A
- ECCN Kodu
- EAR99
- Halogen Free
- Not Halogen Free
