Volume pricing
- 1+ pcs$103.98
- 10+ pcs$98.10
- 100+ pcs$92.54
- 500+ pcs$87.31
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Jesd30 Code
- R-XUFM-X3
- Diode Element Material
- SILICON
- Yayın Yılı
- 2003
- Operating Temperature Junction
- -40°C~150°C
- Kurşunsuz
- Lead Free
- Pin Sayısı
- 98
- Peak Nonrepetitive Surge Current
- 2.4kA
- Forward Current
- 98A
- Case Connection
- ISOLATED
- Number Of Phases
- 1
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Voltage Dc Reverse Vr Max
- 2200V
- RoHS Durumu
- RoHS Compliant
- Speed
- Standard Recovery >500ns, > 200mA (Io)
- Parça Durumu
- Active
- Ambalaj
- Bulk
- Montaj Tipi
- Chassis Mount
- Current Reverse Leakage Vr
- 25mA @ 2200V
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Max Repetitive Reverse Voltage Vrrm
- 2.2kV
- Terminal Pozisyonu
- UPPER
- Min. Çalışma Sıcaklığı
- -40°C
- Diode Type
- Standard
- Voltage Forward Vf Max If
- 1.53V @ 300A
- Additional Feature
- UL RECOGNIZED
- Terminal Sayısı
- 3
- Kılıf / Paket
- Module
- Reverse Voltage
- 2.2kV
- Peak Reverse Current
- 25mA
- Number Of Elements
- 2
- Output Current
- 160A
- Applications
- GENERAL PURPOSE
- Nem Hassasiyeti (MSL)
- Not Applicable
- Montaj
- Screw
- Halogen Free
- Not Halogen Free
- Terminal Formu
- UNSPECIFIED
- Fabrika Tedarik Süresi
- 8 Weeks
- HTS Kodu
- 8541.10.00.80
- Max Forward Surge Current Ifsm
- 2kA
- ECCN Kodu
- EAR99
