Volume pricing
- 1+ pcs$112.33
- 10+ pcs$105.97
- 100+ pcs$99.97
- 500+ pcs$94.31
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Kılıf / Paket
- Module
- Applications
- GENERAL PURPOSE
- Number Of Elements
- 2
- Diode Type
- Standard
- Max Repetitive Reverse Voltage Vrrm
- 1.4kV
- Yüzey Montaj
- NO
- Terminal Pozisyonu
- UPPER
- Terminal Sayısı
- 3
- Additional Feature
- UL RECOGNIZED
- Voltage Forward Vf Max If
- 1.5V @ 300A
- HTS Kodu
- 8541.10.00.80
- Fabrika Tedarik Süresi
- 8 Weeks
- Diode Configuration
- 1 Pair Common Cathode
- ECCN Kodu
- EAR99
- Max Forward Surge Current Ifsm
- 2.4kA
- Rep Pk Reverse Voltagemax
- 1400V
- Nem Hassasiyeti (MSL)
- Not Applicable
- Terminal Formu
- UNSPECIFIED
- Halogen Free
- Not Halogen Free
- Operating Temperature Max
- 150°C
- Diode Element Material
- SILICON
- Jesd30 Code
- R-XUFM-X3
- Kurşunsuz
- Lead Free
- Operating Temperature Junction
- -40°C~150°C
- Yayın Yılı
- 2003
- Parça Durumu
- Active
- Ambalaj
- Bulk
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Montaj Tipi
- Chassis Mount
- Current Reverse Leakage Vr
- 20mA @ 1400V
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Number Of Phases
- 1
- Case Connection
- ISOLATED
- Forward Current
- 89A
- Speed
- Standard Recovery >500ns, > 200mA (Io)
- RoHS Durumu
- RoHS Compliant
- Voltage Dc Reverse Vr Max
- 1400V
