Specifications
- Diode Type
- Standard
- Terminal Pozisyonu
- UPPER
- Yüzey Montaj
- NO
- Nonrep Pk Forward Currentmax
- 2300A
- Terminal Sayısı
- 3
- Voltage Forward Vf Max If
- 1.55V @ 300A
- Kılıf / Paket
- Module
- Applications
- GENERAL PURPOSE
- Number Of Elements
- 2
- Rep Pk Reverse Voltagemax
- 1000V
- Nem Hassasiyeti (MSL)
- Not Applicable
- Terminal Formu
- UNSPECIFIED
- HTS Kodu
- 8541.10.00.80
- Diode Configuration
- 1 Pair Series Connection
- ECCN Kodu
- EAR99
- Diode Element Material
- SILICON
- Jesd30 Code
- R-XUFM-X3
- Current Average Rectified Io
- 96A
- Operating Temperature Max
- 150°C
- Yayın Yılı
- 1999
- Operating Temperature Junction
- -40°C~150°C
- Output Currentmax
- 96A
- REACH Uyumluluk Kodu
- compliant
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Number Of Phases
- 1
- Case Connection
- ISOLATED
- Voltage Dc Reverse Vr Max
- 100V
- Speed
- Standard Recovery >500ns, > 200mA (Io)
- RoHS Durumu
- RoHS Compliant
- Ambalaj
- Bulk
- Parça Durumu
- Obsolete
- Montaj Tipi
- Chassis Mount
- Current Reverse Leakage Vr
- 40mA @ 100V
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
