Volume pricing
- 1+ pcs$281.06
- 10+ pcs$265.16
- 100+ pcs$250.15
- 500+ pcs$235.99
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltage Forward Vf Max If
- 1.36V @ 2200A
- Terminal Sayısı
- 3
- Additional Feature
- HIGH RELIABILITY, UL RECOGNIZED
- Max Repetitive Reverse Voltage Vrrm
- 2.2kV
- Terminal Pozisyonu
- UPPER
- Yüzey Montaj
- NO
- Diode Type
- Standard
- Number Of Elements
- 2
- Applications
- MEDIUM POWER
- Kılıf / Paket
- Module
- Terminal Formu
- UNSPECIFIED
- Halogen Free
- Not Halogen Free
- Nem Hassasiyeti (MSL)
- Not Applicable
- Rep Pk Reverse Voltagemax
- 2200V
- ECCN Kodu
- EAR99
- Max Forward Surge Current Ifsm
- 21kA
- Diode Configuration
- 1 Pair Series Connection
- HTS Kodu
- 8541.10.00.80
- Fabrika Tedarik Süresi
- 8 Weeks
- Operating Temperature Junction
- -40°C~150°C
- Kurşunsuz
- Lead Free
- Yayın Yılı
- 2012
- Reverse Currentmax
- 40000μA
- Operating Temperature Max
- 150°C
- Jesd30 Code
- R-XUFM-X3
- Diode Element Material
- SILICON
- Speed
- Standard Recovery >500ns, > 200mA (Io)
- RoHS Durumu
- RoHS Compliant
- Voltage Dc Reverse Vr Max
- 2200V
- Number Of Phases
- 1
- Case Connection
- ISOLATED
- Forward Current
- 700A
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Montaj Tipi
- Chassis Mount
- Current Reverse Leakage Vr
- 40mA @ 2200V
- Parça Durumu
- Active
- Ambalaj
- Bulk
