Volume pricing
- 1+ pcs$378.06
- 10+ pcs$356.66
- 100+ pcs$336.47
- 500+ pcs$317.43
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Diode Configuration
- 1 Pair Series Connection
- Case Connection
- ISOLATED
- Halogen Free
- Not Halogen Free
- Forward Current
- 540A
- HTS Kodu
- 8541.10.00.80
- Terminal Pozisyonu
- UPPER
- Terminal Sayısı
- 3
- Number Of Elements
- 2
- Operating Temperature Junction
- -40°C~150°C
- Yüzey Montaj
- NO
- Jesd30 Code
- R-XUFM-X3
- Voltage Forward Vf Max If
- 1.48V @ 1700A
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Terminal Formu
- UNSPECIFIED
- Reach Svhc
- No SVHC
- Current Reverse Leakage Vr
- 40mA @ 2600V
- Rep Pk Reverse Voltagemax
- 2600V
- Applications
- GENERAL PURPOSE
- Max Repetitive Reverse Voltage Vrrm
- 2.6kV
- Montaj Tipi
- Chassis Mount
- Voltage Dc Reverse Vr Max
- 2600V
- Kurşunsuz
- Lead Free
- Yayın Yılı
- 2012
- RoHS Durumu
- RoHS Compliant
- Nem Hassasiyeti (MSL)
- Not Applicable
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Output Currentmax
- 573A
- Number Of Phases
- 1
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 8 Weeks
- Diode Element Material
- SILICON
- Diode Type
- Standard
- Speed
- Standard Recovery >500ns, > 200mA (Io)
- Ambalaj
- Bulk
- Additional Feature
- UL RECOGNIZED
- Max Forward Surge Current Ifsm
- 14kA
- Kılıf / Paket
- Module
- ECCN Kodu
- EAR99
