Specifications
- Output Current
- 550A
- Reverse Voltage
- 1.4kV
- Voltage Dc Reverse Vr Max
- 1400V
- Kurşunsuz
- Lead Free
- Yayın Yılı
- 2012
- Current Reverse Leakage Vr
- 30mA @ 1400V
- Nonrep Pk Forward Currentmax
- 11000A
- Max Repetitive Reverse Voltage Vrrm
- 1.4kV
- Montaj Tipi
- Chassis Mount
- Applications
- GENERAL PURPOSE
- Ambalaj
- Bulk
- Diode Element Material
- SILICON
- Diode Type
- Standard
- Speed
- Standard Recovery >500ns, > 200mA (Io)
- Additional Feature
- UL RECOGNIZED
- Kılıf / Paket
- Module
- Max Forward Surge Current Ifsm
- 11kA
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Nem Hassasiyeti (MSL)
- Not Applicable
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Number Of Phases
- 1
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 8 Weeks
- HTS Kodu
- 8541.10.00.80
- Terminal Sayısı
- 3
- Terminal Pozisyonu
- UPPER
- Number Of Elements
- 2
- Operating Temperature Junction
- -40°C~150°C
- Case Connection
- ISOLATED
- Diode Configuration
- 1 Pair Series Connection
- Halogen Free
- Not Halogen Free
- Terminal Formu
- UNSPECIFIED
- Current Average Rectified Io
- 350A
- Pin Sayısı
- 350
- Jesd30 Code
- R-XUFM-X3
- Yüzey Montaj
- NO
- Voltage Forward Vf Max If
- 1.28V @ 1000A
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
