Specifications
- Speed
- Standard Recovery >500ns, > 200mA (Io)
- HTS Kodu
- 8541.10.00.80
- Peak Nonrepetitive Surge Current
- 9.5kA
- ECCN Kodu
- EAR99
- Kurşunsuz
- Lead Free
- Terminal Pozisyonu
- UPPER
- Reach Svhc
- No SVHC
- Ambalaj
- Bulk
- Pin Sayısı
- 260
- Yayın Yılı
- 2012
- Reverse Voltage
- 1.6kV
- Montaj
- Screw
- Max Repetitive Reverse Voltage Vrrm
- 1.6kV
- Voltage Forward Vf Max If
- 1.32V @ 800A
- Peak Reverse Current
- 30mA
- Terminal Sayısı
- 3
- Diode Configuration
- 1 Pair Series Connection
- Additional Feature
- HIGH RELIABILITY, UL RECOGNIZED
- Voltage Dc Reverse Vr Max
- 1600V
- Operating Temperature Junction
- -40°C~150°C
- Terminal Formu
- UNSPECIFIED
- Output Current
- 410A
- Forward Voltage
- 1.32V
- Reference Standard
- IEC-61140
- Max Forward Surge Current Ifsm
- 8.3kA
- Kılıf / Paket
- Module
- Min. Çalışma Sıcaklığı
- -40°C
- Current Reverse Leakage Vr
- 30mA @ 1600V
- Forward Current
- 260A
- Applications
- MEDIUM POWER
- Number Of Phases
- 1
- RoHS Durumu
- RoHS Compliant
- Diode Type
- Standard
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 8 Weeks
- Radyasyon Dayanımı
- No
- Number Of Elements
- 2
- Nem Hassasiyeti (MSL)
- Not Applicable
- Montaj Tipi
- Chassis Mount
- Diode Element Material
- SILICON
