Specifications
- Peak Nonrepetitive Surge Current
- 9.5kA
- HTS Kodu
- 8541.10.00.80
- Speed
- Standard Recovery >500ns, > 200mA (Io)
- Genişlik
- 50mm
- Reach Svhc
- No SVHC
- Kurşunsuz
- Lead Free
- ECCN Kodu
- EAR99
- Terminal Pozisyonu
- UPPER
- Yayın Yılı
- 2012
- Reverse Voltage
- 1.2kV
- Ambalaj
- Bulk
- Pin Sayısı
- 260
- Montaj
- Panel, Screw
- Max Repetitive Reverse Voltage Vrrm
- 1.2kV
- Voltage Forward Vf Max If
- 1.32V @ 800A
- Peak Reverse Current
- 30mA
- Terminal Sayısı
- 3
- Operating Temperature Junction
- -40°C~150°C
- Diode Configuration
- 1 Pair Series Connection
- Additional Feature
- HIGH RELIABILITY, UL RECOGNIZED
- Voltage Dc Reverse Vr Max
- 1200V
- Output Current
- 410A
- Reference Standard
- IEC-61140
- Terminal Formu
- UNSPECIFIED
- Kılıf / Paket
- Module
- Max Forward Surge Current Ifsm
- 8.3kA
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Min. Çalışma Sıcaklığı
- -40°C
- Current Reverse Leakage Vr
- 30mA @ 1200V
- Forward Current
- 260A
- Number Of Phases
- 1
- RoHS Durumu
- RoHS Compliant
- Diode Type
- Standard
- Applications
- MEDIUM POWER
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Number Of Elements
- 2
- Fabrika Tedarik Süresi
- 8 Weeks
- Yükseklik
- 52mm
- Parça Durumu
- Active
- Uzunluk
- 115mm
