Specifications
- Kılıf / Paket
- Module
- Max Forward Surge Current Ifsm
- 2.5kA
- Forward Voltage
- 1.4V
- Output Current
- 160A
- RoHS Durumu
- RoHS Compliant
- Diode Type
- Standard
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Forward Current
- 104A
- Current Reverse Leakage Vr
- 20mA @ 1600V
- Min. Çalışma Sıcaklığı
- -40°C
- Fabrika Tedarik Süresi
- 8 Weeks
- Parça Durumu
- Active
- Yükseklik
- 30mm
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Halogen Free
- Not Halogen Free
- Maks. Çalışma Sıcaklığı
- 150°C
- Montaj Tipi
- Chassis Mount
- Uzunluk
- 92mm
- Nem Hassasiyeti (MSL)
- Not Applicable
- Kurşunsuz
- Lead Free
- Peak Nonrepetitive Surge Current
- 2.9kA
- Genişlik
- 20mm
- Speed
- Standard Recovery >500ns, > 200mA (Io)
- Montaj
- Panel, Screw
- Reverse Voltage
- 1.6kV
- Yayın Yılı
- 2003
- Ambalaj
- Bulk
- Pin Sayısı
- 104
- Voltage Forward Vf Max If
- 1.4V @ 300A
- Max Repetitive Reverse Voltage Vrrm
- 1.6kV
- Operating Temperature Junction
- -40°C~150°C
- Voltage Dc Reverse Vr Max
- 1600V
- Diode Configuration
- 1 Pair Common Cathode
- Peak Reverse Current
- 20mA
