Specifications
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Case Connection
- ISOLATED
- Vceon Max Vge Ic
- 1.55V @ 15V, 25A
- Power Max
- 20mW
- Ntc Thermistor
- Yes
- RoHS Durumu
- ROHS3 Compliant
- Montaj
- Screw
- Number Of Phases
- 1
- ECCN Kodu
- EAR99
- Kılıf / Paket
- Module
- Halogen Free
- Not Halogen Free
- Diode Type
- RECTIFIER DIODE
- Kurşunsuz Kodu
- yes
- Collector Emitter Voltage Vceo
- 1.7kV
- Currentcollector Ic Max
- 40A
- Input
- Standard
- Yayın Yılı
- 2002
- Terminal Formu
- UNSPECIFIED
- Terminal Pozisyonu
- UPPER
- Input Capacitance Cies Vce
- 2.8nF @ 25V
- Voltage Collector Emitter Breakdown Max
- 650V
- Montaj Tipi
- Chassis Mount
- Applications
- GENERAL PURPOSE
- Pin Sayısı
- 3
- Number Of Elements
- 2
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Max Collector Current
- 300A
- Kurşunsuz
- Lead Free
- Pin Sayısı
- 3
- Configuration
- 2 Independent
- Diode Element Material
- SILICON
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Current Collector Cutoff Max
- 40μA
- HTS Kodu
- 8541.10.00.80
- Terminal Sayısı
- 3
- Qualification Status
- Not Qualified
- Igbt Type
- Trench Field Stop
- Element Configuration
- Single
- Parça Durumu
- Not For New Designs
