Specifications
- Parça Durumu
- Not For New Designs
- Igbt Type
- NPT
- Turn Off Timenom Toff
- 390 ns
- Transistor Element Material
- SILICON
- Qualification Status
- Not Qualified
- Terminal Sayısı
- 24
- Polaritychannel Type
- N-CHANNEL
- Current Collector Cutoff Max
- 500μA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Turn On Time
- 105 ns
- Configuration
- Three Phase Inverter
- Yüzey Montaj
- NO
- Number Of Elements
- 7
- Jesd30 Code
- R-XUFM-X24
- Pin Sayısı
- 24
- Terminal Pozisyonu
- UPPER
- Input Capacitance Cies Vce
- 1.5nF @ 25V
- Voltage Collector Emitter Breakdown Max
- 1200V
- Montaj Tipi
- Surface Mount
- Terminal Formu
- UNSPECIFIED
- Yayın Yılı
- 2001
- Currentcollector Ic Max
- 45A
- Terminal Kaplaması
- MATTE TIN
- Kılıf / Paket
- Module
- ECCN Kodu
- EAR99
- RoHS Durumu
- ROHS3 Compliant
- JESD-609 Kodu
- e3
- Fabrika Tedarik Süresi
- 42 Weeks
- Ntc Thermistor
- Yes
- Power Max
- 230W
- Case Connection
- ISOLATED
- Çalışma Sıcaklığı
- 150°C TJ
